Product Information
CombiSets with two burners
Inside the Box
- Connection wire
CS 1012-2 G
CombiSets with two burners
- Subject to technical changes; no liability accepted for the accuracy of the information given.
Product Information
CombiSets with two burners
Inside the Box
- Connection wire
Your advantages
GasStop and ReStart
Automatic reignition for extra safety
Safe cooking: Automatic re-ignition for flame failure If unsuccessful, the gas supply is switched off immediately.
CombiSet – combination
CombiSet appliances leave nothing to be desired
Variety is the program: The CombiSet program offers professional appliances for every type of cooking.
Knobs
Design in detail
Matching convenience: Metal rotary dial controls* complement the design style of the CombiSet elements.
Features depend on model – images are only examples and used for explanation purposes
Design (1)
Stainless-steel frame
The perfect combination
Uniform frame design: No matter which CombiSet units are installed, they always match each other perfectly.
User convenience (4)
Indicators
User-friendliness in detail
Safe and effective: The display with up to three types of indicators.
CombiSet – combination
CombiSet appliances leave nothing to be desired
Variety is the program: The CombiSet program offers professional appliances for every type of cooking.
Knobs
Design in detail
Matching convenience: Metal rotary dial controls* complement the design style of the CombiSet elements.
Inclined control panel
Ergonomics in detail
Perfect looks: The ergonomically arranged control panel simplifies operation.
Safety (1)
GasStop and ReStart
Automatic reignition for extra safety
Safe cooking: Automatic re-ignition for flame failure If unsuccessful, the gas supply is switched off immediately.
Product data sheet
Heating type
Fuel type | Gas |
Design
ProLine | • |
Design
Elegant glass ceramic surface | • |
Miele logo embossed in stainless steel | • |
Cast iron pot rest (matte black enameled) | • |
Cooking zone details
No. of rings | 2 |
Gas burner power rating
Normal burner in kW | 1.85 |
Normal burner in BTU/h | 6300 |
Large burner in kW | 3 |
1st cooking zone/cooking area
Position | front center |
Type | Standard burner |
Max. rating in W | 1600 |
2nd cooking zone/cooking area
Position | rear center |
Type | High-speed burner |
Max. rating in W | 3000 |
User convenience
Operation via knobs | • |
Cleaning convenience
Easy to clean ceramic glass | • |
Safety
Residual heat indicator | • |
Heat indicator | • |
Operational indicator | • |
GasStop | • |
GasStop & ReStart | • |
Technical data
Width in in. (mm) | 11 3/8 (288) |
Height in in. (mm) | 2 7/8 (73) |
Built-in height with mains connection box in in. (mm) | 4 1/4 (106) |
Depth in in. (mm) | 20 1/2 (520) |
Cutout dimensions width in in. (mm) with proud-mounted installation | 10 3/4 (272) |
Cutout dimensions depth in in. (mm) with proud-mounted installation | 19 3/4 (500) |
Weight in lbs. (kg) | 17 (8) |
Total connected load in kW | 4.850 |
Position of gas connection | Hinten links |
Voltage in V | 120 |
Frequency in Hz | 60 |
Power cord length in ft. (m) | 3 (1.2) |
Standard accessories
Connection wire | • |
Optional products and accessories
Downloads, CAD, & apps
- Product sheetPDF
- Warranty conditionsPDF
- Operating and Installation instructionsPDF
Follow the link and you will find all the resources you need for planning and installing any of our products
Whether you are looking to replace an appliance or plan a new kitchen – you will find all the relevant installation drawings for your Miele appliance here. Please note that our products should only be installed and maintained by authorized experts.
Descriptions
CS1012-1G, CS1012-2G, CS1012-2LP (Installation drawing) - USA
