Product Information
CombiSets with two electric cooking zones
Inside the Box
- Razor-blade scraper
- Connection wire
CS 1112 E 240V
CombiSets with two electric cooking zones
- Subject to technical changes; no liability accepted for the accuracy of the information given.
Product Information
CombiSets with two electric cooking zones
Inside the Box
- Razor-blade scraper
- Connection wire
Your advantages
Knobs
Design in detail
Matching convenience: Metal rotary dial controls* complement the design style of the CombiSet elements.
CombiSet – combination
CombiSet appliances leave nothing to be desired
Variety is the program: The CombiSet program offers professional appliances for every type of cooking.
Features depend on model – images are only examples and used for explanation purposes
Design (1)
Stainless-steel frame
The perfect combination
Uniform frame design: No matter which CombiSet units are installed, they always match each other perfectly.
User convenience (4)
Knobs
Design in detail
Matching convenience: Metal rotary dial controls* complement the design style of the CombiSet elements.
Indicators
User-friendliness in detail
Safe and effective: The display with up to three types of indicators.
Inclined control panel
Ergonomics in detail
Perfect looks: The ergonomically arranged control panel simplifies operation.
CombiSet – combination
CombiSet appliances leave nothing to be desired
Variety is the program: The CombiSet program offers professional appliances for every type of cooking.
Safety (1)
Safety turn off
Safe is safe
Clever: If a cooking zone operates at the same power level for an unusually long time, switch-off is automatic.
Features (2)
Keeping warm function
Serve food at the right temperature
Keep food warm without it burning: The pan base is set to the ideal temperature and monitored intelligently.
Vario zone
The right cooking zone for all pan sizes
Variable settings: Whether small, medium or large - there's a cooking zone for every size of pan.
Product data sheet
Heating type
| Fuel type | Electric |
Design
| ProLine | • |
Design
| Elegant glass ceramic surface | • |
| Print design | LightPrint |
| All-round stainless-steel frame | • |
| Proud installation | • |
| Miele logo embossed in stainless steel | • |
Cooking zone details
| No. of rings | 2 |
1st cooking zone/cooking area
| Position | front center |
| Type | Single-circuit ring |
| Size in mm | Ø 145 |
| Max. rating in W | 1200 |
2nd cooking zone/cooking area
| Position | rear center |
| Type | Variable cooking zone |
| Size in mm | Ø 100-180 |
| Max. rating in W | 700/1800 |
User convenience
| Operation via knobs | • |
| Extended ring area | • |
Cleaning convenience
| Easy to clean ceramic glass | • |
Safety
| Safety cut-out | • |
| Overheating protection | • |
| Residual heat indicator | • |
| Operational indicator | • |
Technical data
| Width in in. (mm) | 11 3/8 (288) |
| Height in in. (mm) | 2 7/8 (73) |
| Built-in height with mains connection box in in. (mm) | 3 3/4 (95) |
| Depth in in. (mm) | 20 1/2 (520) |
| Cutout dimensions width in in. (mm) with proud-mounted installation | 10 3/4 (272) |
| Cutout dimensions depth in in. (mm) with proud-mounted installation | 19 3/4 (500) |
| Weight in lbs. (kg) | 15 (7) |
| Total connected load in kW | 3 |
| Voltage in V | 240 |
| Frequency in Hz | 60 |
| Power cord length in ft. (m) | 3 (1.2) |
Standard accessories
| Razor-blade scraper | • |
| Connection wire | • |
Optional products and accessories
Downloads, CAD, & apps
- Product sheetPDF
- Warranty conditionsPDF
- Operating and Installation instructionsPDF
Follow the link and you will find all the resources you need for planning and installing any of our products
- fbxZIP
- dwgZIP
- rfaZIP
- rvtZIP
- ifcZIP
Follow the link and you will find all the resources you need for planning and installing any of our products
Whether you are looking to replace an appliance or plan a new kitchen – you will find all the relevant installation drawings for your Miele appliance here. Please note that our products should only be installed and maintained by authorized experts.
Descriptions
CS 1112 E (Installation drawing) - USA
